Run enough wire to reach the msd ignition control box mounted on the firewall in the engine compartment. Fit new wire from the femalefemale connector and run the wire directly from the spool through an open point on the firewall. By ignition if you are talking about a feed to power up the msd and efi this is a bit of a trick and you need to understand how your car works as original.

Msd Dis Tach Driver Pn 8913

Be6 Msd 6al Wiring Diagram Dodge Wiring Library

Msd 6al Factory Tach Hookup For B Bodies Only Classic Mopar Forum

For more information on tachometers and msd tach adapters see the tachometer section on page 7.

Msd tach adapter wiring diagram mopar. 1 tach adapter 9117 1 butt connector. Some vehicles with factory tachometers may require a tach adapter to operate with the msd. I already have a ready to run msd distributor and coil. Installation instructions tach adapter 2650 561x 10 revc caution.

The voltage on the coil positive must be below 18 volts. In essence you optimize the ignition system so it effectively ignites the fuel charge in the combustion chamber. An a engine needs to be converted from breaker point to electronic ignition system for any performance application. The tach output terminal produces a 12 volt square wave signal with a 20 duty cycle.

Car was running fine. A max performance engine typically intakes a larger fuel air. Harness pn 8877 1996 on gm vehicles. Before i started i called msd and they told me to wire it according to the msd 8360 diagram setup.

The orange and black wires from the second mini harness from the msd box are the wires that you will be connecting to the coil. How to hook up a tachometer to an msd ignition it still runs tach wiring for msd 6a box nastyz28 tach to msd 6al wiring wiring diagram database tach signal wiring explained with or without an msd box foxbody mustang racecar hooking tach to msd 6al vintage mustang forums msd tach signal gmr pickup msd 6 series installation instructions 6a 6al. Strip the end of the trigger wire for the tachometer and place a female to female connector to it. This time an msd 6al 2 ignition box to my small block in my barracuda.

The tach output is generated by the msd so refer to the destructions for the msd which is at their website. The msd wiring harness comes equipped with spade terminals which with the provided adaptors can be connected directly to the coil without modification. To gray tach wwwstreet firecom pn 5520 rk n small red white. The tach adapter cannot be used with a capacitive discharge ignition such as an msd ignition control.

If your gm vehicle has an inline filter it may cause the tach to. Current aftermarket ignition systems and components offer significant benefits for a engines. Today i tried to wire my new msd to my ignition exactly per the instructions and it will not fire. These are the only wires that will be connected to the coil.
