Motogadget M Unit Blue Wiring Diagram

View and download motogadget m unit v2 operating and installation manual online.

Motogadget m unit blue wiring diagram. This enables the munit blue to be connected to our mride smartphone app. 00044800 refer to serial sticker on the device v18. Please visit our technical articles for instructions on wiring the m unit blue as well as comprehensive diagrams complete kit checklist troubleshooting guide and tips for motogadget accessory. The upgrade will take approximately two weeks and costs 120 eur shipping.

What the inputs do what the outputs do and an overall look at this feature rich device. Page 10 simplified vehicle circuit diagramm the circuit diagram below shows a simplified vehicle wiring loom. It is now equipped with 12 inputs and 10 outputs replaceable high quality cable clamps and most notably bluetooth le. This diagram is the general approach used by the revival workshop for m unit blue and basic installations and is offered here as a guideline to be adapted for your own purposes.

The new munit blue has moved on from the established previous version by undergoing significant development and improvements. The 12v m unit terminal can be wired directly to the battery or spliced with the regrec to battery wire the results of both methods are the same. En instruction manual munit blue only valid from serial no. The munit basic is labeld with a red serial number sticker and the munit blue will have a silver serial numer sticker.

Do not get confused by the motogadget diagram where the 12v power to the m unit branches from the same regrec wire to the battery. Maybe could you again for the m unit blue. In this episode of revival cycles tech talk stefan shows you the ins and outs of the motogadget m unit blue. If you use this diagram without referring to the revival approach to m unit wiring you are only taking advantage of one half of our system.

Please refer to connection diagram the light outputs. To upgrade a munit basic to a munit blue the item need to be shipped to motogadget. I saw that you had a mi unit v2 circuit diagram on honda cx. The m unit blue packs unbelievable amount of tech into a tiny package with a footprint smaller than the average smartphone.

Motogadget m unit v2 operating and installation manual. At its core a solid state micro controller and fuse block replacement manages your bikes vital functions while providing a self correcting monitoring system for electrical faults.
