2 load universal dimming room controller lmrc 222 75 c copper wire only santa clara ca 8008798585 industrial control equipment 46a9 indoor use only mounting the controller the room controller mounts to a four square deep junction box using the included mounting plate with the hinge pins extending away from the box as shown.

Wattstopper room controller wiring diagram. Controls lmrc eliminating wiring errors wattstopper dlm local network parameters lmrc digital onoff volt dimming room controller with 2 relays and 2. Line voltage room controller deep j box daylight sensor switch dimmer corner mount sensor ceiling. The success of a dlm network installation and the functionality of the segment to this device is followed exactly as depicted in the wiring instructions and diagram. Enhanced digital single relay plug load room controller.

Load ratings include incandescent magnetic low voltage forward phase compatible electronic low voltage and led drivers neon and cold cathode and dimmable two wire and threewire fluorescent ballasts. It has plug n go automatic configuration for easy installation and maximum energy efficiency. Green ground white neutral black line lmzc 301. Wattstopper digital 1 relay room controller has voltage rating of 120277 volt ac at 5060 hz.

In this tutorial you will learn how to install and connect wallstations sliders occupancy sensors and daylight sensors to your room controller. Lmrc 210 series digital room controllers include one two or three relays to switch a total of 20 amps a high efficiency switching power supply and one 0 10 volt output per relay for control of dimmable loads including electronic ballasts. Wiring for an lmrc 100. Lmrc 220 series digital room controllers include one or two outputs to control a total of up to 20 amps.

View and download wattstopper lmzc 301 installation instructions online. Lmrc digital onoff volt dimming room controller with 1 relay and 1.
